System Parameters

Operating SystemEmbedded Linux operation system

ROM1 GB

RAM4 GB

CPUEmbedded MCU Processor

Display Parameters

Screen Size4.3-inch

Operation MethodPhysical button

TipoColorful LCD

Resolution800 × 480

Video Parameters

Lens1

Resolution

Main stream: 1080p@30fps,720p@30fps

Sub stream: VGA@25fps, VGA@30fps

FOV/

WDRSupport

Supplement LightLow illumination, IR supplement lights

Video Compression StandardH.264

Audio Parameters

Audio Compression StandardG.711 U, G.711 A

Audio InputBuilt-in omnidirectional microphone

Audio OutputBuilt-in loudspeaker

Audio Compression Bitrate64 Kbps

Audio QualityNoise suppression and echo cancellation

Volume AdjustmentAdjustable

Capacity

User Capacity5000

Face Capacity/

Card Capacity200

Linked Network Camera Capacity500

Network Parameters

Communication ProtocolTCP/IP, RTSP

Wired NetworkSupport

Wi-Fi Standard/

Bluetooth Version/

3G/4G Standard/

Device Interfaces

Alarm Input4

Network Interface1 10/100/1000 Mbps self-adaptive Ethernet

TAMPER1

Exit Button1

RS-4852

USB/

Wiegand/

TF Card/

Alarm Output/

Lock Control1

Door Contact Input1

Power Interface1

Performances

Multi-Factor Authentication10000

General

Button/

InstallationFlush mounting

Indicator/

Weight

0.995 kg (without package)

1.592 kg (with package)

Protective LevelIP65

Working Temperature-30 ° C to +60 ° C (-22 ° F to +140 °F)

Working Humidity10% to 90%

Dimensions373 mm × 124 mm × 43.7 mm (14.69" × 4.88" × 1.72")

Battery/

Power Supply12 VDC, 1.5 A

Application EnvironmentOutdoor

Power Consumption≤ 13 W

LínguaEnglish, Traditional Chinese, Arabic, Portuguese (Brazil), Russian, Spanish, Turkish, Vietnamese
